EchoFelt+ Aurora Baffle Array
The Echofelt+ Aurora Baffle Array transforms acoustic performance with its sculptural and highly customizable design. Featuring a variety of striking profiles—wave edges, straight edges, angular peaks, trapezoidal shapes, and more—this innovative ceiling system merges superior sound absorption with bold architectural aesthetics. Designed to enhance both form and function, the Aurora Baffle Array creates visually dynamic environments while optimizing acoustics.
Key Advantages:
Architectural Elegance & Versatility
With its range of unique forms and finishes, the Aurora Baffle Array enables designers to craft distinct acoustic landscapes that enhance any interior style—from sleek and modern to organic and fluid.Exceptional Acoustic Control
Engineered for high NRC ratings, the Aurora Baffle Array effectively reduces reverberation and enhances speech intelligibility, making it ideal for offices, educational spaces, public venues, and commercial interiors.Sustainable & Eco-Friendly
Manufactured from high-quality PET board with recycled materials, this system supports green building initiatives without compromising durability or performance.Effortless Integration
Designed for both new constructions and retrofits, the Aurora Baffle Array offers seamless installation via Unistrut and suspended cable anchor systems, ensuring a secure and efficient mounting process.Fire-Resistant & Safe
Meeting Class A/1 ASTM E-84 fire resistance standards, the Aurora Baffle Array delivers both safety and superior acoustic control.Customizable for Any Space
With multiple thickness options (12mm, and 25mm), an extensive color palette, and custom profiles available, the Aurora Baffle Array allows for a tailored acoustic experience that meets the specific needs of any project.
The Echofelt+ Aurora Baffle Array sets a new benchmark for acoustic innovation, combining cutting-edge design, sustainability, and superior sound management. Whether you’re enhancing a corporate office, auditorium, or hospitality venue, this solution offers the perfect balance of aesthetics and functionality.
Standard Configurations:
-
Ceiling
Suspended from cables., or directly mounted with a rail/unistrut system.
-
Education Sector: Libraries, Learning Commons, Break Out Rooms, Auditoriums, Hallways, Corridors, Music Rooms, Cafeterias, Etc.
Office/Workplace Sector: Offices, Boardrooms, Lunch Rooms, Meeting Rooms, Open Office Areas, Etc.
Entertainment Sector: Theatres, Movie Theatres, Recording Studios, Performance Spaces, Community Halls, Bars & Restaurants, Etc.
Places of Worship: Churches, Mosques, Retreat Centres, Synagogues, Fellowship Halls, Etc.
DOWNLOADS:
Brochure
Specification
LEED Declaration
The Echofelt+ Aurora Baffle Array combines sculptural aesthetics with high-performance sound control. Designed for versatility, it offers customizable profiles, seamless integration, and sustainable materials—enhancing both form and function in any space.
Acoustical Performance
NRC RATING
NOISE REDUCTION COEFFICENT
Noise Reduction Coefficient (NRC) is calculated by averaging the sound absorption coefficients of a material at four frequencies (250 Hz, 500 Hz, 1000 Hz, and 2000 Hz) as measured in a reverberation room according to ASTM C423 standards.
|
Frequency (Hz)
|
||||||||
| 125 |
250 |
500 |
1000 |
2000 |
4000 |
NRC |
||
| 1/2" |
12mm |
0.03 |
0.06 |
0.22 |
0.55 |
0.82 |
0.85 |
0.40 |
| 1" |
25mm |
0.07 |
0.28 |
0.63 |
0.87 |
0.99 |
0.98 |
0.70 |
fire rating/flammability
|
ASTM E-84 |
Class 1 or A |
Size & shape Options
Up to 96” Length (2400mm)
Colour Options
Echofelt+ Standard Colours:
Cleaning & Care Instructions
Our Echofelt products can be cleaned by being blown off with compressed air, using a dry cleaning sponge, damp white cloth or similar. Heavy soiling or stains may require a carpet cleaner which should be used as directed by the manufacturer (Always spot test first). Heavily damaged panels should be replaced.
